CX-250B Plastic film Flow Wrapping Machine

1. Double inverter control, the bag length is set and cut immediately, no need to adjust the idling, one step is in place, saving time and film.

2. Man-machine interface, convenient and quick parameter setting.

3. The fault self-diagnosis function, the fault display is clear at a glance.

4. High-sensitivity photoelectric eye color mark tracking, digital input of the sealing and cutting position, so that the sealing and cutting position is more accurate.

5. Independent PID control of temperature, better suitable for various packaging materials.

6. Positioned stop function, no sticking to the knife, no wasting of film.

7. The transmission system is simple, the work is more reliable, and the maintenance is more convenient.

8. All control is realized by software, which is convenient for function adjustment and technical upgrade, and never lags behind.

Range of products:

Food Industry

Wrapping snacks, chocolates, baked goods, frozen foods, and fresh produce.

Consumer Goods

Wrapping soap bars, cosmetics, and stationery items.

Industrial Products

Packaging hardware, tools, and spare parts.

CX-250B Plastic film Flow Wrapping Machine

Automatic Operation:

The machine automatically feeds, wraps, and seals products at high speeds, making it ideal for high-volume production lines.

How it works

Main Technical Parameters

Technical specifications:

Model	CX-250B
Film width	Max.250mm
Bag length	65~190mm 120~280mm
Bag making width	30~110mm
Product height	Max.40mm
Film roll diameter	Max.320mm
Packaging speed	40~230 packs/min
Power Specifications	220V, 50/60HZ, 2.4KVA
Machine size	(L)3770×(W)670×(H)1450mm
Machine weight	800Kg

Mechanical configuration:

Electric eye temperature control	Shanghai Yatai
PLC	Panasonic
Frequency converter	Panasonic
Power Board	Tai Wan Mingwei
Display frequency	Tianjin Luo Sheng
Terminals	Vid Miqin
solid state relay	Schneider
Leakage switch	Milan DZ47
Indicator light, button, two-position switch, emergency stop switch	Schneider
main power switch	Gree
Motor	Jiang Chen
Proximity switch	Omron

Packing & shipping

Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.

CXM pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,

Packing whole machine in wooden case,no need to joint.

Non-fumigation wooden case,meet import&export requirements
